Double Layer Roll Forming Machine

Double Layer Roll Forming Machine — Dual Profile, One Compact Solution

The Double Layer Roll Forming Machine is an innovative equipment designed to produce two distinct roofing profiles using a single forming base. With a smart design that combines efficiency, space-saving, and easy profile switching, it has become the ideal solution for manufacturers looking to maximize production capacity without expanding floor space.

Two Profiles, One Machine

Instead of operating two separate roll forming lines, the Double Layer Machine integrates two sets of forming rollers—usually for trapezoidal panels and corrugated sheets, or glazed tiles and wall panels. By using an electric or hydraulic shifting system, operators can switch between upper and lower profiles in seconds, without the need for tool change or manual alignment.

Compact Design, High Efficiency

Built with a shared machine frame and a vertically stacked roller system, this equipment occupies only half the space of two traditional machines. This compact layout significantly reduces plant footprint while maintaining full-speed production capability—typically up to 15–25 meters per minute per layer.

Precision Forming, Long Service Life

Each layer is engineered with high-grade 45# steel rollers, CNC-lathed and hard-chrome coated for long wear resistance. The transmission system uses chain drive or gearbox, depending on customer preference, ensuring powerful and synchronized forming even for thicker materials.

Operator-Friendly Interface

Equipped with a touchscreen PLC control panel, the system allows for real-time profile selection, length input, batch quantity setting, and automatic cutting. The seamless integration between production logic and hardware ensures minimal downtime and easy training for operators.

Popular Combinations Available:

• Corrugated sheet + Trapezoidal sheet

• Glazed tile + Trapezoidal panel

• Standing seam + Step tile

Key Advantages:

• Dual-profile production with one machine

• Ideal for limited-space factories or mobile workshops

• Quick layer switching via hydraulic/electric control

• Low maintenance with durable components

• Customizable layout and profile sizes

Whether you're launching a new production line or upgrading your facility for greater flexibility, the Double Layer Roll Forming Machine offers an efficient, space-conscious, and cost-effective solution for versatile panel production.
